Max Output Power 400-700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor

Name: Max Output Power 400700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor
Brand: LDSK
Price: 130 USD

Wholesale Max Output Power 400-700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor from china suppliers

Brand Name : LDSK

Place of Origin : Guangdong, China

MOQ : 1 piece

Price : $130-$210

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram， Paypal

Supply Ability : 50000PCS/Month

Delivery Time : 1-3 workdays

Max Output Power : 100W/50dBm

Working Efficiency : More Than 52%

Frequency : 400-700MHz

Passband Peak to Peak Ripple : Less Than 2dB

Working Temperature : -10~+55 Degree Celcius

Weight : 450g

Packing : Plastic Bag + Paper Box

Transport Package : Carton Box

Specification : 156.5*64.7*24.5mm(excluding connector)

Trademark : LDSK

Origin : Guangdong

HS Code : 8524911000

Frequency Range : WiFi

Application : All

Working Voltage : 24-32V

Samples : US$ 210/Piece

Customization : Available | Customized Request

Contact Now

Product Parameters

--GaN enables high efficiency and high output. The radio frequency and monitoring technical indicators of the power amplifier module stipulate the definition of each port of the module and the shape and structure of the module.

--The power amplifier uses domestic core key components and can operate normally at temperatures of -10~+55°C.

--This document stipulates the radio frequency and monitoring technical indicators of the 600-700MHz 50W power amplifier module, the definition of each port of the module, the appearance and structure of the module, etc.

--This document applies to all aspects of product design, verification, production and quality inspection of the 600-700MHz 50W power amplifier module.

Item name	Technical parameters
Working frequency	400-700MHz
Power	100W
Supply Voltage	DC 24-32V
Max Output Power	50 dBm
Working Efficiency	≥50%
Passband Riplpe	≤2dB
Weight	450 g
Operating Temperature	-10~+55ºC
Power supply requirements	≥3.7A
RF Connector	SMA
Weight	160g
Size	156.564.724.5mm (Excluding SMA)
Connect line red	DC28-30V
Connect line black	GND
Connect line white	ENABLE

Max Output Power 400-700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor

Product Description

Max Output Power 400-700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor

Lead time

Quantity(PCS)	<100pcs	<500	500-1000	>1000
Lead time(Days)	3	3-5	7-12	To be negotiated

Customization

Item	Logo	Frequency	Power	Packing
MOQ(PCS)	1	1	1	1

Company profile

Max Output Power 400-700MHz 100W GaN Module for Anti Drone Anti Fpv Anti Dji Anti Autel Fpv Suppresor

Shenzhen ladasky technology Co,.LTD, specializing in the field of advanced technology. Our company is located in the vibrant city of Shenzhen, known as a hub of innovation and technology in China.

Our main products include RF module and anti FPV, which are designed with cutting-edge technology and strict quality control to meet the diverse needs of our customers. The RF module offers high-performance and stable signal transmission, enabling seamless communication in various applications. The anti FPV solution provides effective protection against unauthorized interference and ensures the security and privacy of video transmission.

We pride ourselves on our strong R&D team, composed of experts and engineers with rich experience and professional knowledge in the field. They are constantly exploring and innovating to bring forth new and improved products that stay ahead of the market trends.

Our manufacturing facilities are equipped with state-of-the-art machinery and adhere to international quality standards. This ensures that every product leaving our factory is of the highest quality and reliability.

Packing and Delivery

Selling Units:	Single item
Single package size:	20X10X5 cm
Single gross weight:	0.2kg
Package Type:	Each piece is individually packed into a bag and then packed into a carton.
